Production-ready shop drawing packages, PDF, DWG and NC files. Detailed to AS 1100 for WA fabricators, mining contractors and structural steel shops. Same standards, same hand, every package.
Issued-For-Approval and Issued-For-Construction revisions, with the file formats your machinery actually reads.
The most expensive thing in shop drawings is the second revision, the one that comes back from the workshop because a connection doesn't match the equipment, or a member won't fit on the truck. We get the workshop's constraints in writing before we open the model: machinery, weld procedures, standard connections, transport limits, paint and finish processes.
Free 30-minute scoping call to walk through the engineering or GA drawings. Written, fixed-scope proposal returned within 48 hours, with turnaround quoted upfront for the whole package, not by the hour.
Typical packages cover structural steel buildings, portal frames, mining infrastructure (conveyor support, chutes, hoppers), mezzanines and equipment platforms, access steel (stairs, walkways, handrails), and retro-fit upgrades to existing plant.
Deliverables are issued through a shared drawing register with revision tracking. NDA available on request, your engineering drawings and our detailing models stay confidential.
Send the engineering drawings, GA or steel schedule. Written, fixed-scope proposal within 48 hours.
Request a Quote
